FPR10 Pro-Lite Black - Fuel Pressure Regulator

Name: FPR10 Pro-Lite Black - Fuel Pressure Regulator
Brand: Turbosmart Australia
SKU: TS-0404-1442
Price: 381.77 AUD
Availability: InStock

In stock

SKU: TS-0404-1442

$419.95 AUD

Prices displayed include GST(Australia). Local taxes will be calculated at check out

Helpful Documents

Data Sheet Link

The Turbosmart FPR Pro-lite 10 Series provides market-leading fuel control and response via actual 1:1 ratio and superior flow and bypass capacity for vehicles with -10 / 10AN fuel feed and -10 / 10AN return fittings. Utilising our Stainless Steel Valve Seat & Milspec Diaphragm, the FPR10 Pro-lite FPR is suitable for all fuel types, including race fuel and aggressive leaded fuels. The FPR10 Pro-lite includes 2 x 10AN inlet pirts and 1 x 10AN fuel return port (or 1 inlet and 1 outlet if a dead head style fuel system is used).

Features 10AN Inlet and Return Stainless Steel Valve Seat Suitable for all fuel types 1:1 Class Leading Ratio & Response Adjustable Base Pressure Between 50psi and 130psi 1/8 NPT Pressure Sensor Port Unique Locking Collar Design Milspec Diaphragm

Need More Fuel Ports? Check out the FPR10 Pro Series (EFI & Mechanical):
FPR10 Pro 5 Port EFI Suit -10AN (Black) TS-0404-1242 FPR10 Pro M 5 Port Mechanical Pump Suit -10AN (Black) TS-0404-1342

Why buy a Turbosmart Fuel Pressure Regulator?

All Turbosmart FPRs are CNC machined in-house from billet aluminium + stainless steel and hand-assembled and tested to ensure maximum precision. Turbosmart FPRs have been designed to provide smooth and stable fuel pressure delivery under all conditions, from idle to full throttle. They are suitable for use with electric and mechanical fuel pumps. The FPR range features an easy screw and lock adjustment and provides a stable 1:1 ratio between fuel and manifold pressure. Each FPR is backed by various accessories such as fuel rail adapters, gauges and fittings to suit the most popular makes and models.

What is a Fuel Pressure Regulator?

A fuel pressure regulator must maintain constant fuel pressure above the intake manifold pressure. Most commonly fitted to the Fuel rail as injectors require a more significant feed pressure than inlet manifold pressure to provide adequate fuel spray for fuel-injected vehicles.

When do I need to Install one? Or upgrade my factory one?

Installing performance fuel injectors or high-flow fuel pumps requires an aftermarket fuel pressure regulator to allow pressure adjustments while maintaining a stable base pressure. They can also maximise a standard fuel system's ability to cope with minor power modifications.

Will Turbosmart FPR work on a Semi Dead-Head System?

Yes. The Turbosmart FPR range is a regulator, and it doesn't matter where you fit it. It will accurately regulate the pressure of the fuel circuit, no matter where on the car you have installed it.

Can these handle Race Fuel?

Yes. With Turbosmart's Unique Diaphragm, stainless salve and seat, we've designed, proven and validated these regulators with the harshest types of fuels around, including Methanol, Lead Race Fuel and E85.

How Does a Fuel Pressure Regulator Work?
